» DVM Test Report: Steady-State|Steady-State|Vin Nominal|80%

Test Details
Schematic 8.1_SyncBuck Efficiency.sxsch
Test Steady-State|Steady-State|Vin Nominal|80%
Date / Time 2/7/2015 10:29:18 AM
Report Directory add_power_losses\Steady-State\Steady-State\VinNominal\80%
Log File report.txt
Screenshot schematic.png
Status PASS
Simulator simplis
Deck input.deck
Init input.deck.init
Measured Scalar Values
Efficiency 95.7546%
Efficiency_nom 95.7546%
ILOAD_Nom 11.2879
Power(Gate_Drive) 61.4631m
Power(LOAD) 28.4416
Power(Line) 29.6412
Power_Gate_Drive_Nom 61.4631m
Power_Line_Nom 29.6412
Power_Load_Nom 28.4416
Power_Q1_Nom 481.82m
Power_Q2_Nom 268.021m
Power_Sum_Of_All_Sources 29.7027
IGate_Drive
AVG
12.3023m
MIN
-552.066p
MAX
7.14031
RMS
219.53m
ILOAD
AVG
11.2879
MIN
11.2211
MAX
11.355
RMS
11.288
ILine
AVG
5.94119
MIN
194.8m
MAX
12.324
RMS
8.0469
Power(Q1)
AVG
481.82m
MIN
-31.8409
MAX
62.8203
RMS
2.712
Power(Q2)
AVG
268.021m
MIN
-10.0726
MAX
10.2077
RMS
834.299m
VGate_Drive
AVG
4.99999
MIN
4.99286
MAX
5
RMS
4.99999
VLOAD
AVG
2.51962
MIN
2.5047
MAX
2.5346
RMS
2.51964
PK2PK
29.8936m
VLine
AVG
4.99406
MIN
4.98768
MAX
4.99981
RMS
4.99406
Measured Spec Values
Max_VLOAD PASS: Max. Output1 Voltage (2.5346) is less than or equal to Max. Output1 Voltage Spec (2.625)
Min_VLOAD PASS: Min. Output1 Voltage (2.5047) is greater than or equal to Min. Output1 Voltage Spec (2.375)
LOAD
ILOAD
VLOAD
SXGPH File simplis_pop12_693.sxgph
Gate_Drive
VGate_Drive
IGate_Drive
SXGPH File simplis_pop12_703.sxgph
Line
ILine
VLine
SXGPH File simplis_pop12_698.sxgph
power
Power(Q1)
Power(Q2)
SXGPH File simplis_pop12_708.sxgph
Other SXGPH Files
SWITCHING#pop simplis_pop12_661.sxgph
DRIVE#pop simplis_pop12_666.sxgph
INPUT#pop simplis_pop12_672.sxgph
IC#pop simplis_pop12_688.sxgph
