» DVM Test Report: Efficiency and Loop Characterization|Efficiency Summary
| Test Details | |
| Schematic | 8.2_LLCClosed Loop.sxsch |
| Test | Efficiency and Loop Characterization|Efficiency Summary |
| Date / Time | 2/7/2015 10:43:51 AM |
| Report Directory | measure_loop_param\Efficiencyand Loop Characterization\Efficiency Summary |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | SKIP |
| Simulator | N/A |
| Measured Scalar Values | |
| VIN Maximum | MIN 94.5907 MAX 96.0248 |
| VIN Minimum | MIN 93.5499 MAX 95.8073 |
| VIN Nominal | MIN 94.0564 MAX 95.9178 |
 Efficiency
VIN Maximum
VIN Minimum
VIN Nominal
|
|
| SXGPH File | simplis_ac42_2731.sxgph |
