» DVM Test Report: Efficiency and Loop Characterization|Vin Maximum|50% Load
| Test Details | |
| Schematic | 8.2_LLCClosed Loop.sxsch |
| Test | Efficiency and Loop Characterization|Vin Maximum|50% Load |
| Date / Time | 2/7/2015 10:39:37 AM |
| Report Directory | measure_loop_param\Efficiencyand Loop Characterization\Vin Maximum\50% Load |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | PASS |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| Efficiency | 95.8681% |
| Frequency(CLK) | 95.409431kHertz |
| Power(LOAD) | 60.491 |
| Power(SRC) | 63.0982 |
| eta_max | 95.8681% |
| gain_crossover_freq | 4.44166k |
| gain_margin | 26.0284 |
| gmargin_max | 26.0284 |
| gxover_max | 4.44166k |
| iload_max | 2.51046 |
| min_phase | 73.1077 |
| phase_crossover_freq | 31.5046k |
| min_phase_freq | 4.44166k |
| phase_margin | 72.8871 |
| pmargin_max | 72.8871 |
| sw_freq_max | 95.409431kHertz |
| ICout | AVG 4.79316u MIN -2.50787 MAX 1.4107 RMS 1.20358 |
| IDQ1 | AVG 157.779m MIN -598.414m MAX 739.219m RMS 365.568m |
| IDQ2 | AVG 157.739m MIN -599.096m MAX 739.283m RMS 365.54m |
| ILOAD | AVG 2.51046 MIN 2.50786 MAX 2.51194 RMS 2.51046 |
| ISRC | AVG 157.779m MIN -598.414m MAX 739.219m RMS 365.568m |
| Im | AVG -80.1394u MIN -490.115m MAX 489.955m RMS 283.205m |
| Ip | AVG 120.136u MIN -522.72m MAX 523.021m RMS 371.283m |
| Ir | AVG 39.9969u MIN -739.279m MAX 739.215m RMS 518.375m |
| Is1 | AVG 1.25568 MIN -5.06917u MAX 3.92265 RMS 1.96967 |
| Is2 | AVG 1.25478 MIN -5.06919u MAX 3.92039 RMS 1.96838 |
| VLOAD | AVG 24.0956 MIN 24.0707 MAX 24.1097 RMS 24.0956 |
| VSRC | AVG 399.984 MIN 399.926 MAX 400.06 RMS 399.984 |
| VSW | AVG 199.984 MIN -725.096m MAX 400.783 RMS 282.308 |
| Vs | AVG -50.2093m MIN -25.0463 MAX 24.8895 RMS 24.8857 |
| Measured Spec Values | |
| Max_VLOAD | PASS: Max. Output1 Voltage (24.1097) is less than or equal to Max. Output1 Voltage Spec (25.2) |
| Min_VLOAD | PASS: Min. Output1 Voltage (24.0707) is greater than or equal to Min. Output1 Voltage Spec (22.8) |
| min_gain_margin | PASS: Gain Margin (26.0284) is greater than Min. Gain Margin (12) |
| min_phase_margin | PASS: Phase Margin (72.8871) is greater than Min. Phase Margin (35) |
 Bode Plot
GAIN
PHASE
|
|
| SXGPH File | simplis_ac23_1484.sxgph |
 LOAD
VLOAD
ILOAD
|
|
| SXGPH File | simplis_pop23_1450.sxgph |
 SRC
VSRC
ISRC
|
|
| SXGPH File | simplis_pop23_1440.sxgph |
 Primary
IDQ1
IDQ2
Im
Ip
Ir
VSW
|
|
| SXGPH File | simplis_pop23_1431.sxgph |
 Secondary
CLK
ICout
Is1
Is2
Vs
|
|
| SXGPH File | simplis_pop23_1445.sxgph |
| Other SXGPH Files | |
| default#1473#pop | simplis_pop23_1473.sxgph |
| Modulator#pop | simplis_pop23_1478.sxgph |
| DVM Bode Plot Input#log#ac | simplis_ac23_1491.sxgph |
