» DVM Test Report: Steady-State|Steady-State|Vin Maximum|30%
| Test Details | |
| Schematic | 8.1_Sync Buck Efficiency.sxsch |
| Test | Steady-State|Steady-State|Vin Maximum|30% |
| Date / Time | 12/10/2015 6:01 PM |
| Report Directory | add_power_losses\Steady-State\Steady-State\VinMaximum\30% |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | PASS |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| Efficiency | 96.2504% |
| Efficiency_Max | 96.2504% |
| IGate_Drive | AVG 12.8322m MIN -583.36p MAX 5.26193 RMS 203.098m PK2PK 5.26193 |
| ILine | AVG 2.0035 MIN 53.7468m MAX 5.49288 RMS 2.89457 PK2PK 5.43913 |
| ILOAD | AVG 4.23302 MIN 4.20433 MAX 4.26138 RMS 4.23305 PK2PK 57.0466m |
| ILOAD_Max | 4.23302 |
| Power(Gate_Drive) | 70.5359m |
| Power(Line) | 11.0109 |
| Power(LOAD) | 10.6659 |
| Power(Q1) | AVG 106.835m |
| Power(Q2) | AVG 43.4057m |
| Power_Gate_Drive_Max | 70.5359m |
| Power_Line_Max | 11.0109 |
| Power_Load_Max | 10.6659 |
| Power_Q1_Max | 106.835m |
| Power_Q2_Max | 43.4057m |
| Power_Sum_Of_All_Sources | 11.0814 |
| VGate_Drive | AVG 5.49999 MIN 5.49474 MAX 5.5 RMS 5.49999 PK2PK 5.26193m |
| VLine | AVG 5.498 MIN 5.49451 MAX 5.49995 RMS 5.498 PK2PK 5.43913m |
| VLOAD | AVG 2.51965 MIN 2.50258 MAX 2.53654 RMS 2.51967 PK2PK 33.9563m |
| Measured Spec Values | |
| Max_VLOAD | PASS: Max. Output1 Voltage (2.53654) is less than or equal to Max. Output1 Voltage Spec (2.625) |
| Min_VLOAD | PASS: Min. Output1 Voltage (2.50258) is greater than or equal to Min. Output1 Voltage Spec (2.375) |
 LOAD
VLOAD
ILOAD
|
|
| SXGPH File | simplis_pop20_1173.sxgph |
 Gate_Drive
VGate_Drive
IGate_Drive
|
|
| SXGPH File | simplis_pop20_1183.sxgph |
 Line
VLine
ILine
|
|
| SXGPH File | simplis_pop20_1178.sxgph |
 power
Power(Q1)
Power(Q2)
|
|
| SXGPH File | simplis_pop20_1188.sxgph |
| Other SXGPH Files | |
| SWITCHING#pop | simplis_pop20_1141.sxgph |
| DRIVE#pop | simplis_pop20_1146.sxgph |
| INPUT#pop | simplis_pop20_1152.sxgph |
| IC#pop | simplis_pop20_1168.sxgph |
