» DVM Test Report: Steady-State|Steady-State|Vin Maximum|90%
| Test Details | |
| Schematic | 8.1_Sync Buck Efficiency.sxsch |
| Test | Steady-State|Steady-State|Vin Maximum|90% |
| Date / Time | 12/10/2015 6:03 PM |
| Report Directory | add_power_losses\Steady-State\Steady-State\VinMaximum\90% |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | PASS |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| Efficiency | 95.3885% |
| Efficiency_Max | 95.3885% |
| IGate_Drive | AVG 13.3893m MIN -601.681p MAX 8.55503 RMS 254.212m PK2PK 8.55503 |
| ILine | AVG 6.09913 MIN 199.092m MAX 13.8087 RMS 8.62977 PK2PK 13.6096 |
| ILOAD | AVG 12.699 MIN 12.6164 MAX 12.7809 RMS 12.6991 PK2PK 164.449m |
| ILOAD_Max | 12.699 |
| Power(Gate_Drive) | 73.5762m |
| Power(Line) | 33.4708 |
| Power(LOAD) | 31.9975 |
| Power(Q1) | AVG 562.903m |
| Power(Q2) | AVG 354.466m |
| Power_Gate_Drive_Max | 73.5762m |
| Power_Line_Max | 33.4708 |
| Power_Load_Max | 31.9975 |
| Power_Q1_Max | 562.903m |
| Power_Q2_Max | 354.466m |
| Power_Sum_Of_All_Sources | 33.5443 |
| VGate_Drive | AVG 5.49999 MIN 5.49144 MAX 5.5 RMS 5.49999 PK2PK 8.55503m |
| VLine | AVG 5.4939 MIN 5.48619 MAX 5.4998 RMS 5.4939 PK2PK 13.6096m |
| VLOAD | AVG 2.51965 MIN 2.50327 MAX 2.5359 RMS 2.51966 PK2PK 32.6289m |
| Measured Spec Values | |
| Max_VLOAD | PASS: Max. Output1 Voltage (2.5359) is less than or equal to Max. Output1 Voltage Spec (2.625) |
| Min_VLOAD | PASS: Min. Output1 Voltage (2.50327) is greater than or equal to Min. Output1 Voltage Spec (2.375) |
 LOAD
VLOAD
ILOAD
|
|
| SXGPH File | simplis_pop27_1593.sxgph |
 Gate_Drive
IGate_Drive
VGate_Drive
|
|
| SXGPH File | simplis_pop27_1603.sxgph |
 Line
ILine
VLine
|
|
| SXGPH File | simplis_pop27_1598.sxgph |
 power
Power(Q1)
Power(Q2)
|
|
| SXGPH File | simplis_pop27_1608.sxgph |
| Other SXGPH Files | |
| SWITCHING#pop | simplis_pop27_1561.sxgph |
| DRIVE#pop | simplis_pop27_1566.sxgph |
| INPUT#pop | simplis_pop27_1572.sxgph |
| IC#pop | simplis_pop27_1588.sxgph |
