» DVM Test Report: Steady-State|Steady-State|Vin Minimum|35%
| Test Details | |
| Schematic | 8.1_Sync Buck Efficiency.sxsch |
| Test | Steady-State|Steady-State|Vin Minimum|35% |
| Date / Time | 12/10/2015 6:04 PM |
| Report Directory | add_power_losses\Steady-State\Steady-State\VinMinimum\35% |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | PASS |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| Efficiency | 96.8590% |
| Efficiency_Min | 96.8590% |
| IGate_Drive | AVG 10.7787m MIN -488.727p MAX 4.07506 RMS 158.661m PK2PK 4.07506 |
| ILine | AVG 2.84706 MIN 81.9686m MAX 5.94956 RMS 3.71388 PK2PK 5.8676 |
| ILOAD | AVG 4.93841 MIN 4.91187 MAX 4.9654 RMS 4.93844 PK2PK 53.53m |
| ILOAD_Min | 4.93841 |
| Power(Gate_Drive) | 48.4787m |
| Power(Line) | 12.798 |
| Power(LOAD) | 12.4429 |
| Power(Q1) | AVG 132.59m |
| Power(Q2) | AVG 53.7835m |
| Power_Gate_Drive_Min | 48.4787m |
| Power_Line_Min | 12.798 |
| Power_Load_Min | 12.4429 |
| Power_Q1_Min | 132.59m |
| Power_Q2_Min | 53.7835m |
| Power_Sum_Of_All_Sources | 12.8464 |
| VGate_Drive | AVG 4.49999 MIN 4.49592 MAX 4.5 RMS 4.49999 PK2PK 4.07506m |
| VLine | AVG 4.49715 MIN 4.49405 MAX 4.49992 RMS 4.49715 PK2PK 5.8676m |
| VLOAD | AVG 2.5196 MIN 2.50605 MAX 2.53337 RMS 2.51961 PK2PK 27.3112m |
| Measured Spec Values | |
| Max_VLOAD | PASS: Max. Output1 Voltage (2.53337) is less than or equal to Max. Output1 Voltage Spec (2.625) |
| Min_VLOAD | PASS: Min. Output1 Voltage (2.50605) is greater than or equal to Min. Output1 Voltage Spec (2.375) |
 LOAD
VLOAD
ILOAD
|
|
| SXGPH File | simplis_pop35_2073.sxgph |
 Gate_Drive
VGate_Drive
IGate_Drive
|
|
| SXGPH File | simplis_pop35_2083.sxgph |
 Line
VLine
ILine
|
|
| SXGPH File | simplis_pop35_2078.sxgph |
 power
Power(Q1)
Power(Q2)
|
|
| SXGPH File | simplis_pop35_2088.sxgph |
| Other SXGPH Files | |
| SWITCHING#pop | simplis_pop35_2041.sxgph |
| DRIVE#pop | simplis_pop35_2046.sxgph |
| INPUT#pop | simplis_pop35_2052.sxgph |
| IC#pop | simplis_pop35_2068.sxgph |
